Sentinel Serries
Key Features
- Automatic Voltage Regulation (AVR)
- Auto-Restart/Auto-Charge
- Generator Compatible
- Cold Start Function
- Off-Mode Charging
- Optional USB/RS232 Communication Port & RJ-11/RJ-45 Protection
- RJ-11/RJ-45 Protection
- EMI Classification; EN 61000-4-5 (surge)
- Automatic Voltage Regulation (AVR)
- Auto-Restart/Auto-Charge
- Auto-Restart/Auto-Charge
- Cold Start Function
- Off-Mode Charging
- Optional USB/RS232 Communication Port & RJ-11/RJ-45 Protection
- RJ-11/RJ-45 Protection
- EMI Classification; IEC 61000-4-5 (surge)
- Automatic Voltage Regulation (AVR)
- Auto-Restart/Auto-Charge
- Auto-Restart/Auto-Charge
- Cold Start Function
- Off-Mode Charging
- Optional USB/RS232 Communication Port & RJ-11/RJ-45 Protection
- RJ-11/RJ-45 Protection
- EMI Classification; IEC 61000-4-5 (surge)
Specification
General
- Capacity
-
600VA/300W
Input
- Nominal Voltage
-
208/220/230/240Vac
- Voltage Range
-
162-290Vac
- Nominal Frequency
-
50/60Hz(Auto sensing)
- Frequency Range
-
40-70Hz
Output
- Nominal Voltage(Batt.mode)
-
220Vac±10%
- Frequency(Batt.mode)
-
50Hz/60Hz ±1%
- Waveform (Batt.mode)
-
Simulated Sine Wave
- Transfer Time
-
±4ms typical
- Overload Protection
-
Circuit breaker or inner firmware protection
Battery
- Battery Voltage
-
12V
- Battery Type
-
12V/7Ah
- Total Battery Quantity
-
1
- Recharge Time (To 90%)
-
8 hours typical
Indicators
- Display
-
LED
- Alarm
-
Batt. Mode, low battery, overload, fault, etc.
Interface
- USB port
-
Optional
- RJ45/RJ11
-
Optional
Management
- Auto Recharge
-
Yes
- Auto Restart
-
Yes
- Power Management Software
-
Yes
Physical
- Dimension (W x H x D)(mm)
-
87 x165x 276
- 4.3
Environmental
- Operating Humidity
-
0-90% non-condensing
- Operating Temperature
-
0-40℃
